Abstract interface for UI text input fields. More...

#include <ITextInput.hpp>

Inheritance diagram for UI::ITextInput:

Collaboration diagram for UI::ITextInput:

Public Member Functions
virtual	~ITextInput ()=default
	Virtual destructor.

virtual void	Update ()=0
	Update the text input internal state (focus, cursor, input).

virtual void	Render ()=0
	Render the text input box.

virtual void	SetOnTextChanged (std::function< void(const std::string &)> callback)=0
	Set callback invoked when text changes.

virtual void	SetPosition (float x, float y)=0
	Set the top-left position of the text input.

virtual void	GetPosition (float &x, float &y) const =0
	Get the current top-left position of the text input.

virtual void	SetSize (float width, float height)=0
	Set the text input size.

virtual void	GetSize (float &width, float &height) const =0
	Get the current size of the text input.

virtual void	SetBackgroundColor (unsigned int color)=0
	Set the background color of the text input box.

virtual void	SetBorderColor (unsigned int color)=0
	Set the border color when the input is not focused.

virtual void	SetActiveBorderColor (unsigned int color)=0
	Set the border color when the input is focused/active.

virtual void	SetTextColor (unsigned int color)=0
	Set the text color.

virtual void	SetPlaceholderColor (unsigned int color)=0
	Set the placeholder text color (when input is empty).

virtual void	SetTextSize (int size)=0
	Set the text size in pixels.

virtual void	SetPlaceholder (const std::string &placeholder)=0
	Set the placeholder text displayed when the input is empty.

virtual void	SetMaxLength (size_t maxLength)=0
	Set the maximum number of characters allowed.

virtual void	SetValidationRegex (const std::string &regexPattern)=0
	Set a regex pattern to restrict allowed characters.

virtual const std::string &	GetText () const =0
	Get the current text content.

virtual void	SetText (const std::string &text)=0
	Set the text content programmatically.

virtual void	Clear ()=0
	Clear the text content.

virtual bool	IsFocused () const =0
	Check if the text input is currently focused/active.

virtual void	SetFocused (bool focused)=0
	Set focus state programmatically.

virtual void	SetFont (int fontHandle)=0
	Set the font handle for rendering text.

virtual void	SetAlign (Align align)=0
	Set alignment mode relative to the window.

virtual Align	GetAlign () const =0
	Get the current alignment mode.

virtual void	ApplyAlignment ()=0
	Apply the current alignment mode to the position.

virtual void	SetEnabled (bool enabled)=0
	Enable or disable the text input.

virtual bool	IsEnabled () const =0
	Check if the text input is enabled.

virtual void	SetPasswordMode (bool passwordMode)=0
	Enable or disable password mode (masks characters with asterisks).

virtual bool	IsPasswordMode () const =0
	Check if password mode is enabled.

Detailed Description

Abstract interface for UI text input fields.

This interface defines a text input box with the following features:

Real-time text input with keyboard handling
Max character limit
Regex-based validation (prevents invalid characters from being typed)
Configurable appearance (size, position, colors)
Placeholder text when empty
Focus/blur states with visual feedback (border colors)
Blinking cursor when active
Optional callback on text change

Definition at line 32 of file ITextInput.hpp.

Constructor & Destructor Documentation

◆ ~ITextInput()

virtual UI::ITextInput::~ITextInput ( )

virtualdefault

Virtual destructor.

Member Function Documentation

◆ ApplyAlignment()

virtual void UI::ITextInput::ApplyAlignment ( )

pure virtual

Apply the current alignment mode to the position.

Note: This modifies the position based on the align setting.

Implemented in UI::RaylibTextInput.

◆ Clear()

virtual void UI::ITextInput::Clear ( )

pure virtual

Clear the text content.

Implemented in UI::RaylibTextInput.

◆ GetAlign()

virtual Align UI::ITextInput::GetAlign ( ) const

pure virtual

Get the current alignment mode.

Returns: Alignment mode.

Implemented in UI::RaylibTextInput.

◆ GetPosition()

virtual void UI::ITextInput::GetPosition	(	float &	x,
		float &	y
	)		const

pure virtual

Get the current top-left position of the text input.

Parameters

x	Output X position in pixels.
y	Output Y position in pixels.

Implemented in UI::RaylibTextInput.

◆ GetSize()

virtual void UI::ITextInput::GetSize	(	float &	width,
		float &	height
	)		const

pure virtual

Get the current size of the text input.

Parameters

width	Output width in pixels.
height	Output height in pixels.

Implemented in UI::RaylibTextInput.

◆ GetText()

virtual const std::string & UI::ITextInput::GetText ( ) const

pure virtual

Get the current text content.

Returns: Current text string.

Implemented in UI::RaylibTextInput.

◆ IsEnabled()

virtual bool UI::ITextInput::IsEnabled ( ) const

pure virtual

Check if the text input is enabled.

Returns: true if enabled.

Implemented in UI::RaylibTextInput.

◆ IsFocused()

virtual bool UI::ITextInput::IsFocused ( ) const

pure virtual

Check if the text input is currently focused/active.

Returns: true if focused.

Implemented in UI::RaylibTextInput.

◆ IsPasswordMode()

virtual bool UI::ITextInput::IsPasswordMode ( ) const

pure virtual

Check if password mode is enabled.

Returns: true if password mode is enabled.

Implemented in UI::RaylibTextInput.

◆ Render()

virtual void UI::ITextInput::Render ( )

pure virtual

Render the text input box.

Note: Must be called between the backend BeginDrawing/EndDrawing calls.

Implemented in UI::RaylibTextInput.

◆ SetActiveBorderColor()

virtual void UI::ITextInput::SetActiveBorderColor ( unsigned int color )

pure virtual

Set the border color when the input is focused/active.

Parameters

color Color in ARGB format (0xAARRGGBB).

Implemented in UI::RaylibTextInput.

◆ SetAlign()

virtual void UI::ITextInput::SetAlign ( Align align )

pure virtual

Set alignment mode relative to the window.

Parameters

align Alignment mode.

Implemented in UI::RaylibTextInput.

◆ SetBackgroundColor()

virtual void UI::ITextInput::SetBackgroundColor ( unsigned int color )

pure virtual

Set the background color of the text input box.

Parameters

color Color in ARGB format (0xAARRGGBB).

Implemented in UI::RaylibTextInput.

◆ SetBorderColor()

virtual void UI::ITextInput::SetBorderColor ( unsigned int color )

pure virtual

Set the border color when the input is not focused.

Parameters

color Color in ARGB format (0xAARRGGBB).

Implemented in UI::RaylibTextInput.

◆ SetEnabled()

virtual void UI::ITextInput::SetEnabled ( bool enabled )

pure virtual

Enable or disable the text input.

Parameters

enabled true to enable, false to disable.

Implemented in UI::RaylibTextInput.

◆ SetFocused()

virtual void UI::ITextInput::SetFocused ( bool focused )

pure virtual

Set focus state programmatically.

Parameters

focused true to focus, false to blur.

Implemented in UI::RaylibTextInput.

◆ SetFont()

virtual void UI::ITextInput::SetFont ( int fontHandle )

pure virtual

Set the font handle for rendering text.

Parameters

fontHandle Font handle (-1 for default font).

Implemented in UI::RaylibTextInput.

◆ SetMaxLength()

virtual void UI::ITextInput::SetMaxLength ( size_t maxLength )

pure virtual

Set the maximum number of characters allowed.

Parameters

maxLength Maximum character count (0 = unlimited).

Implemented in UI::RaylibTextInput.

◆ SetOnTextChanged()

virtual void UI::ITextInput::SetOnTextChanged ( std::function< void(const std::string &)> callback )

pure virtual

Set callback invoked when text changes.

Parameters

callback Function called when the text content changes.

Implemented in UI::RaylibTextInput.

◆ SetPasswordMode()

virtual void UI::ITextInput::SetPasswordMode ( bool passwordMode )

pure virtual

Enable or disable password mode (masks characters with asterisks).

Parameters

passwordMode true to mask characters, false to show them normally.

Implemented in UI::RaylibTextInput.

◆ SetPlaceholder()

virtual void UI::ITextInput::SetPlaceholder ( const std::string & placeholder )

pure virtual

Set the placeholder text displayed when the input is empty.

Parameters

placeholder Placeholder string.

Implemented in UI::RaylibTextInput.

◆ SetPlaceholderColor()

virtual void UI::ITextInput::SetPlaceholderColor ( unsigned int color )

pure virtual

Set the placeholder text color (when input is empty).

Parameters

color Color in ARGB format (0xAARRGGBB).

Implemented in UI::RaylibTextInput.

◆ SetPosition()

virtual void UI::ITextInput::SetPosition	(	float	x,
		float	y
	)

pure virtual

Set the top-left position of the text input.

Parameters

x	X position in pixels.
y	Y position in pixels.

Implemented in UI::RaylibTextInput.

◆ SetSize()

virtual void UI::ITextInput::SetSize	(	float	width,
		float	height
	)

pure virtual

Set the text input size.

Parameters

width	Width in pixels.
height	Height in pixels.

Implemented in UI::RaylibTextInput.

◆ SetText()

virtual void UI::ITextInput::SetText ( const std::string & text )

pure virtual

Set the text content programmatically.

Parameters

text	New text content.

Implemented in UI::RaylibTextInput.

◆ SetTextColor()

virtual void UI::ITextInput::SetTextColor ( unsigned int color )

pure virtual

Set the text color.

Parameters

color Color in ARGB format (0xAARRGGBB).

Implemented in UI::RaylibTextInput.

◆ SetTextSize()

virtual void UI::ITextInput::SetTextSize ( int size )

pure virtual

Set the text size in pixels.

Parameters

size	Font size.

Implemented in UI::RaylibTextInput.

◆ SetValidationRegex()

virtual void UI::ITextInput::SetValidationRegex ( const std::string & regexPattern )

pure virtual

Set a regex pattern to restrict allowed characters.

Parameters

regexPattern Regex pattern string (e.g., "[a-zA-Z0-9]+" for alphanumeric only). Empty string = no restriction.

Note: Validation is applied in real-time: invalid characters are rejected on input.

Implemented in UI::RaylibTextInput.

◆ Update()

virtual void UI::ITextInput::Update ( )

pure virtual

Update the text input internal state (focus, cursor, input).

Note: Should be called once per frame.

Implemented in UI::RaylibTextInput.

The documentation for this class was generated from the following file:

client/UI/ITextInput.hpp
